Given the relatively low cost for tooling, custom foam grips are a very popular choice among our customers. Choose the exact size that you want then add some nubs, grooves, or an ergonomic design.

Inside Diameters

Custom foam grips can be made with virtually any inside diameter. For most applications, we recommend using grips that are 0.125” smaller than the handle that they will be covering. This downsizing will factor in the tolerances and still provide a tight fit. It is important to note that while grips can be made with many different inside diameters, this internal channel must be consistent throughout the grip.

Wall Thickness

Custom grips can be made in wall thicknesses up to about 0.650” thick although the typical wall thickness is approximately 0.250” thick.

Length

Tooling can be designed to make custom buffed grips in most lengths with a maximum of 25”.

Materials

Custom buffed foam grips can be made in many densities and a variety of materials including NPVC and EPDM. Note, any buffed or ground grip will typically lose two to three pounds of density.

Printing, Packaging & More

GripWorks offers a full array of finishing operations to satisfy all of your requirements. The following options are available for all of our foam grips and vinyl grips, including tool grips, handle grips, and just about any grip application possible.

  • Imprinting
  • Punching
  • Slicing
  • Washing
  • Packaging
